2D Drawing Samples by Drawing Type
“Their drafters caught a tolerance stack issue our internal team missed. Saved us a $40k rework.”
— Director of Engineering, Tier-1 OEM
2D CAD Drafting Services We Provide
Manufacturing & Production Drawings
Part and production drawings with full dimensions, tolerances, GD&T and surface finish callouts to ASME Y14.5 or ISO standards, ready for machining, fabrication and inspection.
Shop Fabrication Drawings
Steel detailing, sheet metal flat patterns and weldment sets with weld symbols, cut lists and bend notes, formatted to AISC, AWS D1.1 and your shop's own standards.
Architectural & Floor Plans
Floor plans, elevations, sections and layout drawings drafted in AutoCAD or Revit, at the scale and layer standard your project requires.
As-Built Drawings
As-built drawings created from field measurements, photos and laser scan data, so your 2D records match what was actually built or installed.
Assembly Drawings & BOMs
Assembly drawings with exploded views, balloon callouts and a bill of materials (BOM) that matches the model, ready for manufacturing and procurement handoff.
DETAIL DRAWINGS
Detail Drawings and Callouts
Enlarged section views, joint details and callouts that show how parts fit, fasten or weld, drawn at whatever scale your fabricator needs.
Need something else? We also provide PDF to CAD conversion, paper drawing to DWG conversion, hand-sketch digitization and electrical 2D drafting.
Ask about your case→Our 2D Drafting Process: Sketch In, Production-Ready DWG Out
Most 2D drafting projects complete all 6 steps in 24 to 72 hours. Complex assemblies take 5 to 10 days.
02
Scope
A drafter reviews your files and sends a fixed quote with a deliverables list.
03
Drafting
A senior drafter produces the drawings in your CAD software, version and drafting standard.
04
QA Review
Every drawing is checked for layers, dimensions, tolerances and drafting standards before you see it.
05
Your Review
You review the drawing and mark up changes. Simple revisions come back within 4 hours.
06
Delivery
You receive native CAD files (DWG, RVT or SLDDRW) plus PDF. Every drawing is archived for at least 1 year.
WHY DEVWORKS
Why Teams Outsource 2D Drafting to DevWorks
Most outsourced drafting fails on consistency and speed. We built a system that solves both.
01
24/7 dedicated drafting team
40+ drafters across 3 time zones. Your project moves while you sleep.
02
Multi-time-zone coverage
India + Eastern Europe + LATAM. Deadlines don't care about working hours.
03
Proprietary 6-point QA
Every drawing is reviewed against your standard before delivery. Nothing is sent unchecked.
04
Direct CAD platform access
Optional: we work inside your AutoCAD/Revit license, your PLM, your folder structure.
05
Indexed drawing archive
Every drawing we produce is searchable, version-controlled, and re-issuable for 1 year minimum.
2D Drafting Services FAQs
2D drafting services create dimensioned technical drawings, such as part, assembly, fabrication and as-built drawings, from sketches, PDFs, scans or 3D models. The drawings define geometry, tolerances and materials so a part or structure can be manufactured, built or inspected.
DevWorks 2D drafting starts at $45 per drawing, and monthly retainers start at $3,800 for up to 80 drawings with unlimited revisions. The final price depends on drawing complexity, sheet count and turnaround, and you get a fixed quote before work starts.
Most 2D drafting projects are delivered in 24 to 72 hours, and complex assemblies take 5 to 10 days. For large projects, we can add drafting capacity within 24 hours.
Send whatever you have: hand sketches, photos, PDFs, scanned paper drawings, DWG files, field measurements, laser scan data or 3D CAD models. Include your title block and drafting standard if you have one, and we reply with a fixed quote and deliverables list.
Yes. We convert PDFs, scanned paper drawings and hand sketches into editable DWG files with clean layers, dimensions and title blocks set to your standard.
We draft in AutoCAD, Revit, MicroStation, BricsCAD, Inventor, SolidWorks and NX. Every delivery includes the native file, such as DWG, RVT or SLDDRW, plus a PDF, and the source files are yours to keep and edit.
Yes. A senior drafter checks every drawing against ASME Y14.5 (formerly ANSI Y14.5) or ISO 1101, covering datum references, tolerance zones, surface finish callouts and title block accuracy before delivery.
Unlimited revisions are included until you approve the drawing, at no extra charge. Simple mark-up changes are returned in under 4 hours.
Yes. We sign an NDA before you share any files, and every drawing we produce remains your property.
