Already manufacturable on the day you receive the model.
Production-grade modeling, flat patterns, weldments, and shop drawings — built to your bend table, your tolerances, and your fabricator's machine envelope.
One team. Every layer of sheet metal engineering.
From first concept geometry to a fabricator-ready drawing pack — tightly scoped capabilities, modular by design.
Production-ready 3D sheet metal modeling
Native SolidWorks, Inventor, and NX models with proper bend tables, K-factors, gussets, and weldments — built to your fabricator's machine envelope.
Flat patterns & DXF export
Press-brake-ready DXF and STEP exports with bend lines, notations, and material call-outs — drop straight into your CAM.
Weldments & assemblies
Multi-body assemblies, weld beads, gussets, and frame structures with full BOM rollup.
Manufacturing drawings
GD&T-compliant 2D drawings with views, dimensions, weld symbols, and revision blocks.
Reverse engineering
From scanned point clouds and physical samples back to clean parametric sheet metal models.
Manufacturability audit
Every model is checked against bend radii, tool clearances, hole-to-edge ratios, and material availability before release.
Six checkpoints from your CAD to fabricator-ready files.
A predictable rhythm — every project moves through the same numbered checkpoints, with reviews built in at every stage.
01
CAD intake & brief lock
You share native CAD or scans. We lock material grade, thickness, finish, and the target fabricator's machine envelope.
02
Geometry clean-up
Imported geometry is repaired, simplified, and rebuilt as parametric sheet metal — no orphan surfaces, no broken bends.
03
Bend table calibration
K-factor, bend radius, and bend deduction are dialed to your press brake's actual tooling — not generic defaults.
04
Weldments & assemblies
Multi-body assemblies built with weld beads, gussets, and ribs. BOM rolls up automatically as the model evolves.
05
DFM audit + drawing pack
Full DFM checklist runs before drawings are cut. GD&T-compliant 2D drawings issued with revision blocks.
06
Handoff & change-control
Final native models, flat patterns, DXF, STEP, and drawings — with a tracked ECN process for every future revision.
Industries we serve
Modeling tuned to how your industry actually fabricates.
Different sectors, different bend tables, tolerances, and standards. We adapt the pipeline — and the deliverable — to your reality.
Industrial enclosures
From wall-mount control boxes to floor-standing cabinets — modeled with proper folds, knockouts, gland plates, and gasket grooves. Drawings include door hinge specs, lock prep, and standard cut-outs.
Bend table
Yes
Drawing pack
2D + 3D
BOM
Auto-rolled
Lead time
2 weeks
The 12-point DFM checklist on every part.
Before any drawing leaves the studio, every part runs through a fixed 12-point manufacturability audit — the same one your contract manufacturer would run, but two weeks earlier.
- ✓
Bend radius vs material thickness
- ✓
Hole-to-edge ratio
- ✓
Hole-to-bend distance
- ✓
Internal corner relief
- ✓
Tool clearance & punch reach
- ✓
Flange minimum lengths
- ✓
Tab-and-slot alignment
- ✓
Material grain direction
- ✓
Hardware insertion clearance
- ✓
Welding access & joint type
- ✓
Surface finish allowances
- ✓
Material commercial availability
Drawings that fabricators don't have to redraw.
Every drawing pack is delivered against the standards your machine shop already uses.
ISO 2768
General tolerances
ASME Y14.5
GD&T compliance
DIN 6930
Sheet metal parts
ANSI B4.1
Limits & fits
BS 4870
Welding spec
ISO 9001
Quality management
Parts shipped, drawings approved, redlines avoided.
FEATURED CASE
INDUSTRIAL ENCLOSURES
·
NORTHWIND CONTROLS
From 14-week drawing backlog to 5-day turnaround on every new SKU.
We rebuilt their wall-mount enclosure family in parametric SolidWorks with a calibrated bend table and reusable feature library. New SKUs now ship as fabricator-ready packs in under five days.
−65%
Drawing turnaround
12k+
Parts modeled
0
Manufacturing redlines
HVAC
Custom rooftop ductwork — 800+ unique parts, one parametric library
Variable-length transitions and elbows generated from a single skeleton model.
800+ parts
1 library
−40% modeling hrs
FOOD-GRADE
Stainless commercial kitchen line — IP-rated and weld-prepped
304-grade fabrication with hygienic radii, weld access, and full BOM rollups for 14 SKUs.
14 SKUs
304 SS
Hygienic-design
Frequently asked questions
SolidWorks, Inventor, NX, CATIA, Creo, Fusion 360, Rhino. We also accept neutral formats (STEP, IGES, X_T) and rebuild as parametric sheet metal in your target system.
Yes. We ask for your press brake tooling specs and dial in the K-factor, bend radius, and bend deduction before any model leaves QA. Generic defaults are never used.
Yes — all drawings are issued to ASME Y14.5 or ISO 2768 depending on your standard. We include full dimensioning, weld symbols, surface finish, and revision blocks.
A single part from CAD intake to approved drawing pack typically takes 3–5 business days. Complex assemblies or weldments are quoted individually.
Yes. Every weldment and multi-body assembly includes a complete BOM with part numbers, material, thickness, and cut-list quantities — ready for your ERP or procurement team.
Yes. We deliver in your native format (SolidWorks, Inventor, NX) and can work within your vault structure. Files are checked in with revision tracking and ECN documentation.
